1) Purpose & Outcomes

Goal: Provide a multi‑modal, hierarchical interface for observing, directing, and auditing a complex agent swarm. The HMI must make it easy to:
  • See _what_ is happening (tasks, flows, dependencies), _where_ (which agent/tier), _how far_ (progress), and _at what cost_ (time, tokens, $).
  • Detect problems early (stalls, deadlocks, context overrun, heartbeat misses) and intervene safely (pause, reassign, rollback).
  • Scale from tiny jobs (1–2 agents) to large swarms (40+ agents) without losing clarity.
    • Primary outcomes
  • Real‑time situational awareness (≤1s perceived lag).
  • Hierarchical roll‑ups from worker → manager → director → VP.
  • Cost and token usage visibility, with budget alerts.
  • Voice and sonification channels for eyes‑busy/voice‑only use (driving), and silent visual modes for office/lab use.

    • 2) Personas & Scenarios

  • VP Engineering (you): Needs the 10,000‑ft view and quick drill‑downs. Cares about progress, risk, cost, and time‑to‑green.
  • Directors (Code/Models/Data/DevSecOps/Docs): Track lane health, approve gates, resolve blockers, enforce policy.
  • Managers: Triage work, restart/kill stuck tasks, keep heartbeats green, maintain quality gates.
  • Operators/ICs: Observe their agent instance, confirm instructions, and provide human approvals.
    • Key scenarios
  • Refactor‑wide change across repo and docs; watch work stream out to workers then roll up to completion.
  • Detect a stuck worker (2 missed heartbeats); manager restarts; VP sees the bubble clear.
  • Token budget breach at a worker; Token Governor triggers Save‑State → Clear → Resume; HMI shows cause and recovery.

    • 3) Architecture Integration (Ports & Services)

  • PAS Web UI: Flask @ 6101 (this HMI).
  • Event Stream: WS/SSE @ 6102 (live updates).
  • PAS Orchestrator API: FastAPI @ 6100 (job submit/approve).
  • Gateway: @ 6120 (single client entrypoint).
  • Registry: @ 6121 (service discovery & heartbeats).

    • HMI consumes:

  • Heartbeats (heartbeat.schema.json) and status updates (status_update.schema.json).
  • Routing receipts from Gateway (artifacts/costs/.json).
  • Job cards and manifests for provenance.

    • 4) Views (UI Surfaces)

    4.1 Hierarchical Dashboards (per‑agent Flask mini‑UIs, consistent look)

  • Agent card: name, role, parent, children, rights (perm‑codes), ctx limit/usage, current job, ETA, artifacts, last heartbeat.
  • Roll‑up summaries: parent dashboards aggregate children (counts, progress, alerts).

    • 4.2 Global Tree (Message Flow Graph)

  • Dynamic, zoomable DAG/tree.
  • Nodes: agents; size ∝ live token usage / load; color = status; ring indicates role (coord/exec/system).
  • Edges: animated “light bars” for messages; brightness = throughput.

    • 4.3 Sequencer (Activity Timeline)

  • Rows = tiers (Workers bottom → Managers → Directors → VP top).
  • Time on X‑axis; glyph length = task duration; thickness = live token usage; color = state.
  • A moving playhead shows “now”.

    • 4.4 Sonification (Musical Notes)

  • Optional audio stream: short, rate‑limited notes for task events (assign, start, progress, done).
  • Pitch: higher = lower tier; instrument: differentiates agents; note length: task duration hint.

    • 4.5 Spoken Summaries (Narration)

  • One‑sentence summaries on assign/complete events.
  • Voice depth: maps to hierarchy (VP = deep; workers = light).
  • Mute per‑tier and per‑agent; batch mode for “digest” every N minutes.

    • 4.6 Timeline Scrubber (Replay)

  • Scrub backward to replay the last 24–72h with the sequencer/graph synchronized; export as MP4/GIF for post‑mortems.

    • 5) Signals, Encodings, and Alerts

    5.1 Status → Color Map

  • queued=gray, running=blue, waiting_approval=purple, blocked=orange, paused=teal, error=red, done=green.

    • 5.2 Audio Map (defaults; user‑configurable)

  • Tier → pitch range: VP (C2–G2), Directors (C3–G3), Managers (C4–G4), Workers (C5–G5).
  • Event → note: assign=staccato, start=attack, progress=short sustain, complete=resolve cadence.
  • Instrument families: VP=contrabass, Directors=cello, Managers=viola, Workers=violin; alternates per agent to avoid collisions.

    • 5.3 Narration Map

  • Per‑event templates:

    • - _Assign:_ “Director‑Data assigned ‘Chunk wiki batch‑7’ to Manager‑North (ETA 14m).”

    - _Heartbeat:_ “Manager‑North healthy, 35% load, tokens 12.3k/32k.”

    - _Complete:_ “Worker‑CPE‑12 finished 184 files; 0 errors; 12m 41s.”

    5.4 Alerts & Policies

  • Heartbeat miss: >2 intervals ⇒ red alert at node + banner; auto‑action: notify parent and Manager.
  • Context breach: ≥75% window ⇒ Token Governor Save‑State → Clear → Resume; HMI shows link to summary artifact.
  • Cost spike: rolling p95 > threshold or $/min > budget ⇒ yellow alert with top contributors.

    • 6) Controls (Operator Actions)

  • Pause/Resume agent or subtree.
  • Reassign task to different agent (via Gateway target filters).
  • Restart worker (kills run, preserves artifacts).
  • Approve/Reject pending gates (PRs, destructive ops).
  • Mute/solo tiers for audio; set narration cadence (live vs digest).
  • Toggle views (Tree/Sequencer), tie playhead to real time or replay mode.

    • 7) Data & Contracts (Consumed by HMI)

  • heartbeat.schema.json → run_id, agent, ts, progress[0..1], status, token_usage{ctx_used,ctx_limit}, resources{cpu,mem,gpu_mem}.
  • status_update.schema.json → event: {accepted|started|awaiting_approval|approved|rejected|soft_timeout|hard_timeout|escalated|completed}.
  • job_card.schema.json → task metadata, resource requests, parents/children, approvals_required.
  • routing_receipt.schema.json → source, resolved target, timings, cost_estimate, ctx info.

    • Retention:

  • artifacts/hmi/events/ LDJSON for 30d (configurable).
  • Audio/narration logs (JSON sidecar) for audit (optional).

    • 8) Performance & SLOs

  • UI render latency: ≤250ms P95.
  • Event propagation: ≤1s end‑to‑end P95.
  • Graph layout stability: node jitter < 20px/frame at 60fps.
  • Audio rate limit: ≤8 notes/sec global; per‑agent ≤2 notes/sec.

    • 9) Security, Privacy, and Approvals

  • Respect PRD approvals: git push, deletions, DB destructive, external POSTs require explicit approval.
  • Mute narration/notes in sensitive spaces; privacy mode hides file paths and vendor names.
  • All actions audited to artifacts/hmi/audit/ with user, ts, before/after.

    • 10) Accessibility & UX

  • Color‑blind safe palette; redundant shapes/labels for status.
  • Full keyboard/TUI parity for core actions.
  • Captions/real‑time transcript for narration; per‑tier volume sliders.
  • Mobile layout for quick checks; voice‑only control set (basic commands).

    • 11) Extensibility & Integrations

  • Plugins: add visualization panels, custom alert rules, new audio instruments/packs.
  • Claude /agents: ship a _HMI Operator_ subagent with Gateway tool for approvals and view toggles.
  • AR Prototype: optional “Holographic Task Cube” (WebXR) in Phase‑3.

    • 12) API (HMI Facade)

  • GET /hmi/agents → list with hierarchy, status, ctx, rights.
  • GET /hmi/tree → graph JSON (nodes, edges, metrics).
  • GET /hmi/seq?from..to → sequencer strips.
  • GET /hmi/metrics → roll‑ups (tokens/min, $/min, errors).
  • WS /hmi/stream → unified event bus (beats, status, receipts).
  • POST /hmi/action → pause/resume/reassign/approve with reason.

    • 13) Visual Encodings (Spec)

  • Node size: linear map of ctx_used/ctx_limit (min 8px, max 48px).
  • Edge pulse speed: proportional to message rate (cap at 4 pulses/s).
  • Sequencer thickness: token rate (tokens/s); cap to preserve legibility.
  • Legends: hoverable, always visible in top‑right.

    • 14) Audio Encodings (Spec)

  • Pitch ladder per tier (VP low → Workers high).
  • Event envelope (ADSR): assign (short attack), start (attack+short decay), progress (staccato ticks), complete (resolve).
  • Ducking during narration to avoid overlap.

    • 15) Milestones & Deliverables

    P0 (1–2 days):
  • Agent list, per‑agent cards, roll‑up counts; basic Tree.
  • WS/SSE stream; log to artifacts/hmi/events/.
  • Status colors & heartbeat alerts.
    • P1:
  • Sequencer view + timeline scrubber.
  • Cost/token roll‑ups; receipts ingested.
  • Operator actions (pause/resume/reassign/approve).
    • P2:
  • Sonification + spoken summaries (mute/solo, digest mode).
  • Replay export; anomaly flags (stall, token breaches).
    • P3:
  • AR “Holographic Task Cube” prototype (WebXR).
  • Plugin API + presets; mobile quick‑status.

    • 16) Acceptance Criteria

  • Live Tree and Sequencer reflect events with ≤1s lag (P95).
  • Node size, color, and thickness encode load/status/token usage clearly.
  • Two missed heartbeats raise red alert and visible breadcrumb to parent/VP.
  • Token Governor actions surface in HMI with link to Save‑State summary.
  • Costs visible by agent, tier, and run; top N contributors listed.
  • Audio and narration can be toggled per‑tier and per‑agent; rate‑limited.
  • P0–P2 features demoed on a real multi‑agent run; logs preserved.

    • 17) Open Questions

  • Preferred TTS backend for narration (local vs vendor).
  • Default audio pack/instrument set.
  • Minimum retention for events vs audio sidecars (30/90 days?).
  • Whether to auto‑suggest scaling ("add N workers") from HMI based on saturation.

    • 18) Appendix — Quick Mappings & Tables

    18.1 Event Types

    EventSourceTriggers job_createdManager/DirectorSequencer block appears, graph edge from parent → child accepted/startedWorkerNote: start; narration (optional) progressWorkerSequencer thickness update awaiting_approvalAnyVP/Director banner + action button soft_timeoutManagerOrange alert; suggest restart hard_timeoutManagerRed alert; kill + requeue completedWorker/ManagerResolve chord; roll‑up progress ↑ heartbeatAllNode glow refresh; missed x2 ⇒ alert cost_receiptGatewayCosts/latency charts update

    18.2 Rights (perm‑codes)

    [F:rw] filesystem, [B:x] bash, [G:x] git, [P:x] python, [N:rw] network, [S:x] sql/psql, [D:x] docker.

    18.3 Status Colors

    queued gray · running blue · waiting_approval purple · blocked orange · paused teal · error red · done green

    19) One‑Screen Summary (for Execs)

  • Where are we? Tree + roll‑up bar (done/running/blocked).
  • What’s it costing? $/min and tokens/min with top spenders.
  • What’s risky? Alerts panel (missed beats, stalled tasks, budget breaches).
  • What can I do? Approve / Reassign / Pause‑Resume / Open Report.
